Bonfiglioli 306 Series Planetary Gear Reducer

The best replacement of Bonfiglioli 307 gearbox.

This Planetary Gearboxe is for Twin Shaft Concrete Mixers of 0.5cbm.

 SNAKE

R306 Series Planetary Gear Reducer

Technical Specifications

Bonfiglioli 306 Series Planetary Gear Reducer – Technical

(Typical parameters for concrete mixer application, e.g., 306/307 / 309/310/313...)

Parameter

Metric

Imperial

Notes

Model

R306

R306

For twinshaft concrete mixer

Type

Planetary

Planetary

Heavyduty, high shock load, Bonfiglioli series

Nominal Output Torque

8,000 N·m

5,900 lb-ft

Standard rating for concrete mixing application

Max. Output Torque

9,500 N·m

7,010 lb-ft

Peak torque under heavy shock loads

Ratio (Standard)

23.5 : 1

23.5 : 1

Optimized for 0.5m³ twinshaft mixers

Input Speed

1,800 rpm

1,800 rpm

Standard IEC / NEMA motor speed

Output Speed

~76.6 rpm

~76.6 rpm

Calculated at 1,800 rpm input (1800 / 23.5)

Recommended Motor

2 × 15 kW

2 × 20.1 hp

Dual motor configuration for 0.5m³ mixer

Output Shaft Diameter

70 mm

2.76 in

Splined / keyed shaft for mixer coupling


Inquiry or Consult

SNAKE Planetary Gearbox complies with EU standard

SNAKE produced gearbox by our own heat treatment furnace.All of our machines are from Germany to ensure the most tiny tolerance.

  • 1
  • 2
  • 3
GET MORE INFORMATION

 SNAKE

Bonfiglioli 306 – Key Features

Key Features

  • High torque density and compact structure
  • Heavy-duty design for shock loads and harsh conditions
  • Excellent sealing against dust, water and concrete slurry
  • Wide gear ratio range for mixer speed matching
  • Compatible with IEC motors and hydraulic motors
  • Optional integrated electric/hydraulic brake
  • High efficiency, low noise and long service life
  • Flexible output shaft and mounting options
  • Easy maintenance and reliable performance
055c51cd-f935-48ea-8950-180855e2b557-恢复的

 SNAKE

OPERATING TEMPERATURE

-20°C to +80°C (-4°F to +176°F)

Item

Specification

Input Speed (n₁)

1,470 rpm

Output Speed (n₂)

73 rpm

Rated Input Power (Pₙ₁)

15 hp (11 kW)

Rated Output Torque (Tₙ₂)

26,130 lb-in (2,950 Nm) / Max Output Torque: 70,805 lb-in (8,000 Nm)

Output Shaft Diameter

Ø74 mm

Weight

198 lb (90 kg)

Gear Ratio

21.85


Online message

tihuan
Submit

 SNAKE

Product parameters and related specifications
